Yamaha RX-A2A Aventage 7.2 Channel AV Receiver, Black

View PDF
View PDF
View PDF
View PDF
View PDF
View PDF
View PDF
This product is currently not available for purchase
SALE

Key Features

  • 7.2 Channels deliver up to 100W of power to prodcue powerful audio
  • YPAO microphone with RSC tailors the sound to suit your room's acoustics
  • Enjoy immersive 8K visuals thanks Dolby Vision, HDR 10+, and seven HDMI inputs
  • Supports Wi-Fi, Bluetooth, AirPlay 2, Spotify Connect and MusicCast multi-room audio
Questions? Email [email protected] or call 01706 878444

Yamaha RX-A2A Aventage 7.2 Channel AV Receiver, Black Overview

The Yamaha RX-A2A Aventage 7.2 Channel AV Receiver is a mid-range receiver in Yamaha's Aventage range. All six of the Aventage AVRs boast studio-grade sonic and video enhancement cased in a glossy black frame. As a mid-range model, the RX-A2A satisfies standard home cinema configurations with 100 Watts of power (8 ohms, 2 ch. driven) and anti-resonance technology for resistance to electrical interference.


The RX-A2A is not only more affordable than the top-of-the-range RX-A6A and RX-A8A models, but features a range of surround sound and video support from Dolby, and DTS too. The XR-A2A is compatible with a wireless rear speaker for extra dimension in your speaker setup and works with the MusicCast app for controlling your AVR and multi-room streaming with zone 2.

Product Ref: 209722

Full Description

View Full Description

Aventage is Quality Assured

Anti-Resonance Technology (A.R.T.) helps make the range of Aventage AVRs spectacularly stable for better sonic quality. A fifth leg in the centre of its base supports the XR-A2A unit and dampens external vibration. The unyielding chassis alongside general anti-vibration enhancements further protect your sound from any unwanted rattle.

Get Set and Go

On your marks, get set up, go! Utilising the AV setup guide app takes away any confusion while installing your new Yamaha RX-A2A. The app is designed to guide you through connectivity, cables and setting configuration so you can start using your AVR as soon as possible. An in-depth user manual, available to access and read online, offers an alternative source of information and guidance.

Multi-room Magic

MusicCast offers a range of convenient features to the RZ-A2A. The MusicCast app allows you to control your AVR, its multiple streaming platforms, and connections in one clever and functional application. Furthermore, the RX-A2A is compatible with the MusicCast 50 or MusicCast 20 wireless streaming rear speakers for additional sound dimension in any home cinema configuration.

Glorious Gaming

With a future firmware update, your RX-A2A can be upgraded to include auto-low-latency-mode (ALLM), variable-refresh-rate (VRR), quick frame transport (QFT), and quick media switching (QMS). These modern gaming essentials will contribute to heightened responsiveness, load speed, and smoother transitions once installed.

3D Sound Effects from Yamaha

The RX-A2A is embedded with Yamaha’s own CINEMA DPS HD3 technology. This offers 17 programmed sound-field effects with three-dimensional effects suited to different content. From the grand ambience of a concert hall in Vienna to the commentator’s box at a major sporting event, explore the possibilities of Yamaha’s CINEMA surround sound.

Measured and Controlled Sound

With this model of Yamaha’s Aventage range, YPAO is included with the multi-point measurement and reflected sound control functions. This allows you to measure the acoustics of your room and let Yamaha’s calibration technology correct early reflections.

SCENE

Scene buttons on your Aventage AVR are for saving your favourite channel/input/output settings as pre-sets for faster access. Once pre-sets are saved, they can be selected by simply selecting the appropriate SCENE button either on your remote control or on the AVR unit itself.

Next-Gen eARC

Enhanced Audio Return Channel (eARC) upgrades upon its predecessor, ARC. This feature helps to enhance the 4K content streamed via HDMI 2.1 from Yamaha AVRs. eARC supports multichannel formats from Dolby and DTS to experience sound as it should be.

Super Streaming Services

Find a range of popular streaming services built-in and ready to use from your RX-A2A. Platforms like Spotify, Amazon Music, Napster, Pandora, TIDAL, Deezer, Qobuz, and SiriusXM are available and will keep your music and playlists synchronised across other devices. Control where music plays in different rooms of your home with MusicCast.

Key Features

  • 7.2 channel set-up delivers 100 W power out to ensure robust audio quality
  • YPAO with RSC and multi-point measurement
  • Dolby Atmos with Height Virtualisation mimics in-ceiling speakers
  • DTS:X and DTS-HD Master Audio enable sound objects to move throughout your space
  • Compressed music enhancer returns lost quality to your audio files
  • High slew rate amplifier with a specially designed circuit for stability
  • HDR10+ and 8K/60Hz, 4K/120Hz capabilities for quality video
  • ALLM, VRR, QMS, and QFT are available via future firmware update
  • MusicCast App offers control over your AVR and connected devices
  • Voice control is attainable once paired with a third-party AI device

What’s in the Box?

  • Yamaha RX-A2A Aventage 7.2 Channel AV Receiver, Black
  • DAB/FM antenna
  • Power cable
  • YPAO microphone
  • YPAO microphone base and pole
  • Remote control
  • Two AAA batteries (for remote control)
  • Quick start guide
  • Safety brochure
  • YPAO with R.S.C. and multi-point measurement

Specifications

Dimensions

Dimensions (W x H x D) 435 x 171 x 372 mm
Dimensions with antenna up (W x H x D) 435 x 245 x 372 mm
Weight 10.2 kg

Amplification

Channels 7.2
Rated Output Power (1kHz, 1ch driven) 125 W (8 ohms, 0.9 THD)
Rated Output Power (20Hz-20kHz, 2ch driven) 100 W (8 ohms, 0.06 THD)
Maximum Effective Output Power (1kHz, 1ch driven) 150 W (8 ohms, 10 THD)
Rated output power (1kHz, 1ch driven) 115 Watts (6 ohms, 0.9 THD)
Rated output power (20Hz-20kHz, 2ch driven) 80 Watts (6 ohms, 0.06 THD)
Maximum effective output power (1kHz, 1ch driven) 145 Watts (6 ohms, 10 THD)
High slew rate amplifier Yes
Standby power consumption (IR only) 0.1 Watts
Auto power standby Yes
ECO mode Yes

Surround Sound Processing

CINEMA DSP Yes
DSP programs 17
Dialogue level adjustment Yes
Virtual presence speaker Yes
Virtual surround back speaker Yes
Dialogue lift Yes
SILENT CINEMA / Virtual CINEMA Yes
Dolby Atmos Yes
Dolby Atmos Height Virtualiser Yes
Dolby TrueHD Yes
Dolby Digital Plus Yes
Dolby Surround Yes
DTS:X Yes
DTS-HD Master Audio Yes

Audio

File format MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 192 kHz / 24-bit, WAV / AIFF: up to 192 kHz / 32-bit, DSD: up to 11.2 MHz
Pure Direct Yes
Compressed music enhancer Yes
YPAO multi-point measurement Yes
YPAO volume Yes
Adaptive DRC (Dynamic Range Control) Yes
Initial volume & maximum volume setting Yes
A.R.T. Wedge Yes
Bi-amp capability Yes
Audio delay Yes (0-500 ms)
DA converter 384 kHz / 32-bit BB PCM5101A

Video

HDMI eARC Yes
HDMI audio return channel Yes
HDMI pass-through 8K / 60 Hz, 4K / 120 Hz* HDR10+
HDMI up-scaling Yes up to 4K
Dolby Vision Yes
HDR 10+ Yes (via firmware update)
VRR/ALLM/QMS/QFT Yes (via firmware update)

Connectivity

MusicCast surround Yes
HDMI input / output 7 / 1
HDMI CEC Yes
USB input Yes
Network port Yes
Wi-Fi Yes (2.4 / 5 GHz)
AirPlay 2 Yes
Bluetooth Yes (SBC / AAC)
Front AV input USB
Digital audio input / output: optical 1 / 0
Digital Audio input / output: coaxial 1 / 0
Analogue audio input / output 4 / 0
Phono input Yes
Pre-out 2.2-ch
Headphone output 1

Tuner

FM/AM tuner Yes (Availability varies by region)
DAB tuner Yes (Availability varies by region)

User Interface

On-screen display Graphical user interface
SCENE Yes (8 sets)
App control Yes (iPhone / iPad / Android phone / tablet)
Web browser control Yes
Remote control unit Yes

Zone Control

Zone 2 audio output Pre-out
Powered zone Zone 2
+12V trigger output 1
Party mode Yes
