Arcam AVR10 AV Receiver w/ Dirac Live Room Correction
Key Features
- Dolby Atmos & DTS:X 7.1.4 decoding
- 4K (UHD) HDMI2.0b with HDCP2.2
- *HDMI 2.1 8K Upgrade Available In The Latter of 2021
- 7 HDMI inputs, 2 HDMI outputs, eARC compatible
- Dirac Live room correction
Arcam AVR10 AV Receiver w/ Dirac Live Room Correction Overview
Stunning Realism, Immersive Sound
The AVR10 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With an impressive 12-channel surround solution and featuring all the latest CODECs from Dolby, DTS and IMAX Enhanced, the AVR10 exemplifies sound quality and engineering excellence.
The AVR10 features the efficient class AB amplification for a level of transparency that delivers the most captivating sound. Audiophile listening experiences are optimised with full 12-channel Dirac calibration on board as well as simple streaming with a mobile device using the native app of choice via Apple Airplay2 or Google Chromecast.
Product Ref: 208153
Full Description
View Full Description
Stunning Realism, Immersive Sound
The AVR10 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With an impressive 12-channel surround solution and featuring all the latest CODECs from Dolby, DTS and IMAX Enhanced, the AVR10 exemplifies sound quality and engineering excellence.
The AVR10 features the efficient class AB amplification for a level of transparency that delivers the most captivating sound. Audiophile listening experiences are optimised with full 12-channel Dirac calibration on board as well as simple streaming with a mobile device using the native app of choice via Apple Airplay2 or Google Chromecast.
- Dolby Atmos & DTS:X 7.1.4 decoding
- 4K (UHD) HDMI2.0b with HDCP2.2
- *HDMI 2.1 8K Upgrade Available In The Latter of 2021
- 7 HDMI inputs, 2 HDMI outputs, eARC compatible
- Dirac Live room correction
- ESS 9026PRO audiophile DAC
- Class AB power amplification - Uses frame-type transformer
- Wifi / Ethernet, RS232 and IR control
- Google Cast/UPnP capability for streaming audio
- Bluetooth
- Free MusicLife iOS and Android UPnP and control app
Continuous power output, per channel, 8Ω/4Ω
| 2 channels driven, 20Hz - 20kHz, <0.02% THD | 80W/100W |
|---|---|
| 2 channels driven, 1kHz, 0.2% THD | 85W/120W |
| 7 channels driven, 1kHz, 0.2% THD | 60W/85W |
| Residual noise & hum (A-wtd) | <0.15mV |
Stereo Line Inputs
| Maximum Input | 4.5V rms |
|---|---|
| Nominal Sensitivity | 1V, 2V, 4V (User Adjustable) |
| Input Impedance | 47kΩ |
| Signal/Noise Ratio (A-wtd ref 100W) Normal/Stereo Direct | 100dB/110dB |
| Frequency Response | 20Hz—20kHz ± 0.2dB |
Preamplifier Outputs
| Nominal Output Level | 1V RMS (max. 5V RMS) |
|---|---|
| Output Impedance | 560Ω |
| THD+N (20Hz—20kHz) | –100dB |
Headphone Output
| Maximum Output Level into 32Ω | 5Vrms |
|---|---|
| Output Impedance | <100Ω |
General
| Mains Voltage | 110–120V or 220–240V, 50–60Hz |
|---|---|
| Power Consumption (Maximum) | 1.5kW (Thermal Dissipation Approx. 5200 BTU/hour) |
| Power Consumption (Idle, Typical) | 90W (Thermal Dissipation Approx. 340 BTU/hour) |
| Power Consumption (Standby) | <0.5W |
| Dimensions W x D (Including Speaker Terminals) x H (Including Feet) | 433 x 425 x 171mm |
| Weight (Net) | 16.5kg |
| Weight (Packed) | 19.8kg |
| Supplied accessories | Mains leadRemote Control with 2 x AAA BatteriesManualDAB/FM Aerial3 x WiFi/Bluetooth AntennasCalibration MicrophoneUSB Cable |
