Key Features
- 60 Watts of dynamic Class AB power output
- Supports a range of inputs including MM Photo Stage and PC-USB
- Wireless aptX Bluetooth ensures high-fidelity wireless
- Premium D to A converter for a open, spacious sound
DISC Rotel A12 MKII Integrated Amplifier, Silver Overview
The Rotel A12 MKII Integrated Amplifier is ideal for spacious and reproduction of your music collection. Despite its sleek design, it delivers two times 60 Watts of Class AB power into 8 ohms. The A12 MKII supports sources such as MM Phono Stage, analog, digital PC-USB and wireless Bluetooth. And with a 32-bit DAC and optimised circuits, you'll get the most out of your HiFi system.
Product Ref: 230630
Full Description
View Full Description
AB Power
The A12MKII uses 2 x 60 Watts of Class AB power to give your speakers a robust foundation to work with
Phono Input
With a moving magnet phono input, you can get the most out of your turntable connection
Wireless aptX™ Bluetooth
aptX™ Bluetooth ensures a high fidelity wireless listening experience
Digital to Analog Converter
Using a Texas Instruments premium 32-bit/384kHz Digital to Analog Converter, the A12MKII delivers a spacious, open listening experience
Certified Roon Tested
The A12MKII is certified Roon tested, so you can play your high-fidelity digital music collection with ease
Specifications
| Maximum Power Output | 120 watts/ch (4 ohms) |
|---|---|
| Continuous Power Output | 60 watts/ch (8 ohms |
| Total Harmonic Distortion | < 0.018% |
| Intermodulation Distortion | < 0.03% (60 Hz : 7k Hz, 4:1) |
| Frequency Response | Phono Input: 20 Hz - 20k Hz (0 ± 0.5 dB)Line Level Inputs: 10 Hz - 100k Hz (0 ± 0.5 dB) |
| Damping Factor | 220 (20 Hz - 20k Hz, 8 ohms) |
| Input Sensitivity / Impedance | Phono Input (MM): 3.4 mV / 47k ohmsLine Level Inputs (RCA): 230 mV / 24k ohms |
| Input Overload | Phono Input (MM): 50 mVLine Level Inputs: 4 V |
| Preamplifier Output / Impedance | 1.2 V / 470 ohms |
| Tone Controls - Bass / Treble | ± 10 dB at 100 Hz / 10k Hz |
| Signal to Noise Ratio | Phono Input (MM): 90 dBLine Level Inputs: 100 dB |
| Frequency Response | 10 Hz - 90k Hz (0 ± 2 dB, Max) |
| Signal to Noise Ratio | 103 dB (IHF A-weighted) |
| Input Sensitivity / Impedance | 0 dBfs / 75 ohms |
| Preamplifier Output Level | 1.4 V (at -20 dB) |
| Coaxial / Optical Digital Signals | SPDIF LPCM (up to 24-bit / 192k Hz ) |
| PC-USB | USB Audio Class 1.0 (up to 24-bit / 96k Hz )USB Audio Class 2.0(up to 32-bit / 384k Hz )**Driver installation requiredRoon Tested |
| Power Requirements | Europe: 230 V, 50 HzUSA: 120 V, 60 Hz |
| Power Consumption | 230 watts |
| Standby Power Consumption | < 0.5 watts |
| BTU (4 ohms, 1/8th power) | 632 BTU/h |
| Dimensions (W x H x D) | 430 x 93 x 345 mm17 x 3 5/8 x 13 1/2 in |
| Front Panel Height | 80 mm, 3 1/8 in |
| Weight (net) | 8.76 kg, 19.31 lbs. |
| Finish | Silver |
