Key Features
The Arcam A5+ is perfect for music lovers who want to enjoy high-quality listening with family and friends, whether through loudspeakers or headphones. Building on the award-winning Arcam Radia A5, the A5+ takes things further with an enhanced power supply and even more versatile connectivity. The result is a cleaner, more dynamic sound with extra headroom that makes a real difference when driving a pair of quality speakers.
New wireless features also set it apart from the original A5. With Snapdragon Sound, you get uncompressed audio over Bluetooth, while Auracast lets you share the same track wirelessly across multiple compatible headphones or speakers without pairing. Alongside digital and analogue inputs, the finely tuned phono stage ensures your vinyl playback is as detailed and engaging as your streaming sources. With these thoughtful upgrades, the A5+ combines the musicality of the A5 with added power and convenience for today?s listening habits.
Product Ref: 350634
"The A5+ is a wonderful addition to Arcam’s family of amplifiers, offering a sound that blends class-leading insight with a tangible sense of musicality."
| Number of inputs | 3 (RCA pairs) |
|---|---|
| Signal/noise ratio (A-wtd, ref. 50W, 1V input) | 106dB |
| Frequency response | 20Hz—20kHz ± 0.2dB |
| Input impedance | 47kΩ + 100pF |
|---|---|
| Frequency response (ref. RIAA curve) | 20Hz—20kHz ± 1dB |
| Supported Sample Rates (kHz) | 192176.49688.24844.1 |
|---|---|
| Bit depths (bit) | 2416 |
| Frequency response (filter 1) | 20Hz—20kHz ± 0.2dB |
| Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) | 109dB |
| Maximum output level (RMS) into 32Ω/300Ω | 2.5V/5V |
|---|---|
| Load range | 16Ω - 2kΩ |
| Bluetooth Version | 5.4; A2DP Sink/Source, AVRCP, BLE, SBC, AAC, aptX, aptX HD and aptX Lossless, LE Audio, Auracast |
|---|---|
| Bluetooth Transmitter Frequency and Power | 2,400 MHz to 2,483.5 MHz: <20dBm |
| Continuous power output (0.5 THD), per channel | 2 channels driven, 20Hz - 20kHz, 8Ω 50W |
|---|---|
| Continuous power output (0.5 THD), per channel | 2 channels driven, 1kHz, 4Ω 75W |
| Harmonic distortion, 80 power, 8Ω at 1kHz | 0.003 |
| Mains voltage | 100V or 110–120V or 220–240V, 50–60Hz |
|---|---|
| Power consumption (maximum) | 350W |
| Power consumption (standby) | <0.5W |
| Dimensions W x D (including speaker terminals) x H (including feet) | 431 x 344 x 83mm |
| Weight (net) | 8kg |
| Weight (packed) | 11kg |
| Product Code | ARCAMA5+ |
| EAN | 1200130028588 |
